Overview
This header collector ball flange kit takes the place of typical three bolt flange type connections and allows for a leak free and gasket free connection. Both ends feature 2.50-inch inside diameter slip-fit connections. Welding required. Available in var
Features
- 2.50-inch Collector to 2.50-inch Tubing
- Slip-fit Connections for Easy Assembly
- Replaces Three Bolt Header Flanges
- 16 Gauge Aluminized Steel Tubing
- Leak-free Ball and Socket Seal
- Flowmaster Quality
Application
- Universal Item – Not a direct fit. Some adaptation required.
Specs
| Attachment Method | Ball & Socket Flange |
| Automotive Item Grade | High Performance Part |
| Bolts/Studs Included | Yes |
| Brand | Flowmaster |
| California Proposition 65 Required | No |
| Color | Gray |
| Emission Code | 5 |
| Header Flange Thickness (in) | 0.375 |
| Height (in) | 3 |
| Inlet Connection Type | Straight Pipe |
| Inlet Diameter (in) | 2.5 |
| Material | Aluminized Steel |
| Material Gauge | 16 |
| Outlet Connection Type | Straight Pipe |
| Outlet Diameter (in) | 2.5 |
| Product Type | Exhaust Accessories |
