Overview:
The 12-920 universal in-line fuel pump is intended for Throttle Body EFI, Multipoint EFI and Forced Induction Multipoint EFI systems. It is designed to work in-line, not inside the tank, so installation is a snap. The 12-920 is rated for continuous duty service and have been tested up to 2,500 hours.
Features:
- Draws 5 amps at 15 psi
- Will feed up to 800 horsepower throttle body EFI units
- Will feed up to 700 horsepower multipoint units
- Will feed up to 600 horsepower forced induction multipoint units
- OE proven design
- Lightweight and compact
- Rubber isolator, mounting clamps and electrical hardware included
- 3/8″ barbed fittings included
- Not designed for use on aircraft of any type.
Application:
| Year | Make | Model | Submodel | Engine Size |
|---|---|---|---|---|
| Universal |
Specs:
| Application | Universal |
|---|---|
| Bracket Color | Black |
| Brand | Holley |
| Coast Guard Approved | Yes |
| Emission Code | 3 |
| Forced Induction HP@43PSI | 600 |
| Fuel System | Carbureted |
| Fuel System | EFI |
| Fuel Type | Gasoline |
| GPH@15PSI | 80 |
| GPH@43PSI | 67 |
| GPH@60PSI | 62 |
| GPH@8PSI | 85 |
| Inlet Size | 10mm x 1.0 |
| LPH@15PSI | 302 |
| LPH@43PSI | 254 |
| LPH@60PSI | 235 |
| LPH@8PSI | 322 |
| Material | Steel |
| Naturally Aspirated HP@15PSI | 800 |
| Naturally Aspirated HP@43PSI | 700 |
| Naturally Aspirated HP@8PSI | 850 |
| Outlet Size | 10mm x 1.0 |
| Product Type | EFI Part |
| Pump Body Color | Silver |
| Warning | California Proposition 65 |
| Warranty | Limited 90 Day |
